Principle

Co2 Fractional system shoot a beam 10600 nm which is then split into numbers of microscopic beams, producing tiny dot, or pixel-like zones within the selected area of the skin, leaving the other zones within it perfectly intact.

Principle
Therefore, the heat only passes deeply through the fractional damaged area.This allows the skin to heal much faster if the whole area was treated. During the skin self-resurfacing, a great number of collagen is produced for skin rejuvenation,eventually the skin will look much healthier and younger.

 Application

1 Remove acne, acne scar, scar and so on;
2 Dispel wrinkle around the eyes, crow's-feet, and wrinkle formed by lack of water;
3 Effectively reduce the wrinkle on the face, forehead, the joints and striae gravidarum;
4 Dispel freckle, nevus zygomaticus and other spots formed by hyperchromic pathological changes;
5 Tighten skin and lift face;
6 Remove striae gravidarum and other deep scars

 Technical Specification

Electrical Requirements : AC 110V± 10% 60Hz AC 220V± 10% 50Hz
Beam Delivery:7 joint arm
Wavelength:10600nm Cooling Air cooling
Aiming wavelength :635nm Output mode Continuous, super pulse,fractional
Focal Spot: Diameter ≤ 0.2mm Operating mode Continuous, operation with,intermittent loading
Power of Aiming Beam: ≤ 5mw
Whether Preview or not :Yes
Pulse Interval :1ms-5000ms, every stepping 1ms
Times of scanning :1th-20 th, every stepping 1th
Pulse Width : 0.1ms-10ms, every stepping 0.1ms
Scanning Mode :Disorder emitting, to one side as the base emitting in order, emitting by maximum distance
Output Power: 30W , RF metal tube from USA
Output Pattern :7; Beeline, triangle, right square, rectangle, hexagon, rotundity, ellipse etc
Spots Interval: 0.1mm-2.6mm, every stepping 0.1mm
Pattern Size :Diagonal length from 0.1mm to 20mm is adjustable at random
Net Weight :26 KG
Dimension: 65cm x 36cm x 31cm
Packing Weight :45 KG
Packing size :82cm x 54cm x 67cm

 Features

1. USA-imported RF metal tube generator, high quality excellent performance
2. 10'' color touch screen display, Fractional and Normal two moods
3. Fractional mood For scar, wrinkle, acne scar, stretch mark, skin resurfacing etc
4. Normal mood for medical surgery
5. Portabe & smart design, easy for move and daily maintenance;
6. Smaller focal spot, stronger penetration and powerful output energy;
7. Strong aluminium case to protect your machine safety during the delivery
8. Medical CE approval, ISO13485: 2003 and ISO9001: 2008.
